GEMS

GEMS® is a general purpose electromagnetic simulation software which includes several electromagnetic (EM) simulation solvers. GEMS comprises high-performance parallel Integral Equation solvers such as the Method of Moments (MOM) and the Multilevel Fast Multipole Algorithm (MLFMA). GEMS also offers High Frequency Electromagnetic solvers utilizing Physical Optics (PO), Physical Theory of Diffraction (PTD) and Shooting and Bouncing Rays (SBR) methods for high frequency problems such as scattering from electrically large structures.

Feature illustration Feature box Feature illustration top Feature illustration Feature box Feature illustration top
Feature 01 Feature 01

MOM & MLFMA Solvers

  • Surface integral equations utilizing the Combined Field Integral Equation (CFIE) and JMCFIE for complicated structures involving multiple dielectric and metallic regions.
  • Powerful preconditioners for the MLFMA.
  • Parallel iterative and direct solvers.
  • Application of various integral equations through the use of variable integral equations coefficients.
  • Efficient parallelization using the Message Passing Interface (MPI) communication protocol to minimize the pre/post processing tasks and matrix fill times.
  • Impedance Boundary Condition (IBC) implementation.

Feature 02 Feature 02

High Frequency Electromagnetic Solvers

  • Physical Optics/Ray-Tracing, SBR, Physical Theory of Diffraction
  • GO/Ray-tracing, GTD/UTD
  • Ray-tracing for penetrable/impenetrable surfaces.
  • Accurate treatment of multilayered coatings.
  • Fast frequency sweep in Ray-Tracing.
  • Parallel ray-tracing in SBR.
  • Adaptive mesh splitting based on source location.
  • Efficient shadowing algorithm.

Feature 03 Feature 03

Key Features

  • Radar Cross Section (RCS) calculation.
  • Antenna modeling using Equivalent Current Reconstruction (ECR) technique.
  • Antenna coupling.
  • Antenna placement workflow.
  • Scattering Center Computations using surface currents.
  • Source types: Plane wave, Far field patterns, Elementary electric/magnetic dipole distributions, Spherical Wave Expansion (SWE) Modes, Delta-Gap, Complex source point (CSP) beams
  • Parallelization on Windows clusters and High Performance Computing (HPC) systems running variants of Linux/Unix.
  • Efficient scalability with increasing problem size.
  • Surface mesh sanity checks.
